New

Central Point CP 400/12FSe - 400l/min - 12 users

Central Point CP 400/12FSe - 400l/min - 12 users

Central Point CP 400/12FSe - 400l/min - 12 users

Central Point CP 400/12FSe – 400l/min – up to 12 users, stand mounted, inverter control, with a water meter, PLC controller, full reporting of media consumption

Technical Guidance

Need help choosing? Discuss your application with us.

Product Specifications

Check dimensions, materials and compatibility before ordering.

Delivery Information

Contact us for delivery options and estimated lead times.

Product Support

Get in touch about documentation, care or product queries.

Central Point CP 400/12FSe – 400l/min – up to 12 users, stand mounted, inverter control, with a water
meter, PLC controller, full reporting of media consumption

outlet pipe: 2 1/2”

supply pipe: 2 1/2’’

engine power: 2 x 7,5 kW

pump output pressure: 25 bar

water pump supply: 2 bar minimum

500 kg

Reference 20.01.03.02.E

MPN 20.01.03.02.E

Connection: outlet pipe: 2 1/2” | Connection: supply pipe: 2 1/2’’ | Specification: engine power: 2 x 7,5 kW | Pressure: pump output pressure: 25 bar | Water pressure: water pump supply: 2 bar minimum | Weight: 500 kg
